Mechanical Jacks yog siv feem ntau rau kev sib dhos daim ntawv thov, los tuav lossis txhawb nqa, muaj peev xwm ntawm 1.5 txog 25tonne. Compact tsim nrog collapsible lever muab kev ua haujlwm yooj yim thiab kev saib xyuas yooj yim. Tus kheej locking, anti-kickback ua haujlwm lever txo kev raug mob.
Cov yam ntxwv ntawm Mechanical Jack
1. Thaum tshav kub kub-kho siab precision iav thiab iav racks tuaj yeem paub tseeb tias lub tes tsho ruaj khov ua haujlwm. Tsim nyog iav piv yuav ua kom lub teeb tes quab yuam.
2. Foldable tes crank yog portable thiab yooj yim rau kev khiav lag luam.
3. Mechanical jack boasts ob txoj kev nqa, uas yog nqa los ntawm ntiv taw lossis nqa los ntawm sab saum toj.
4. Qhov no cov ntsia hlau jack tau dhau qhov ntsuas ntsuas load.
5. Lub braking system tuaj nrog ratchet log pawl nres, ua kom nres nrawm dua thiab txhim khu kev qha.
Qauv | 1.5 Ton | 3Ton | 5Ton | 10Ton | 16 Ton | 20 Tuj | 25 ton | |
Rated Peev xwm t | 1.5 | 3 | 5 | 10 | 16 | 20 | 25 | |
Test Load kN | 18.4 | 36.8 | 61.3 | 122.5 | 196 | 245 | 306.3 | |
Lub zog tes ntawm tag nrho load N | 150 | 280 | 280 | 560 | 640 | 640 | 640 | |
nrug mm | 300 | 350 | 350 | 410 | 320 | 320 | 320 | |
Qhov siab tshaj lifting | F | 60 | 70 | 80 | 85 | 95 | 100 | 110 |
H | 600 | 730 | 730 | 800 | 800 | 860 | 970 | |
Qhov ntev | A | 163 | 197 | 189 | 250 | 275 | 275 | 350 |
B | 190 | 200 | 239 | 293 | 320 | 335 | 340 | |
C | 273 | 296 | 335 | 498 | 514 | 529 | 538 | |
D | 100 | 130 | 140 | 140 | 150 | 150 | 170 | |
E | 55 | 60 | 71 | 86 | 78 | 78 | 80 | |
G | 110 | 140 | 170 | 170 | 180 | 180 | 200 | |
K | 113 | 127 | 127 | 248 | 250 | 250 | 250 | |
R | 225 | 250 | 275 | 300 | 300 | 380 | 380 | |
Net Nyhav kg | 13.5 | 21.2 | 28.5 | 46.8 | 65 | 75 | 91 | |
Lub tsev steel ruaj khov ua kom lub neej ua haujlwm ntev, txawm tias siv tas li. Lub tshuab ua kom tiav lub thawv iav nrog qhov pom qhov sib piv kom ntseeg tau qhov tsawg kawg ntawm kev siv zog thiab kev ua haujlwm du. Lub load yog tuav ruaj ntseg nyob rau hauv txhua txoj hauj lwm. Nyob rau hauv lub load nres lub axial nres siab yog generated los ntawm lub load nws tus kheej, yog li, nws yog proportional rau qhov loj ntawm lub load.
 |  | |
 |  |
