G100 nqa saw feem ntau yog tsim los rau qhov xav tau siab ntawm thaj chaw nqa nyiaj siv ua haujlwm. Nws' tau ua los ntawm cov khoom zoo siab muaj zog alloy hlau hauv Suav teb thiab muaj 25% siab dua lub zog dua li qhov loj me ntawm qib 80 nqa saw, uas pab koj txo qhov loj thiab qhov hnyav ntawm koj cov saw hauv tib txoj haujlwm yuav tsum muaj peev xwm.
EN818-2, AS2321 Luv Txuas G100 Lifting Chain
KHOOM CODE | NOMINAL SIZE Dn (hli) | PITCH (hli) | Ua haujlwm LOAD LIMIT LWM (KN) | QHOV TSEEB FORCE (KN) |
Z818-2C04 | 4 | 12 | 6.3 | 25.1 |
Z818-2C06 | 6 | 18 | 14 | 56.5 |
Z818-2C07 | 7 | 21 | 19 | 77 |
Z818-2C08 | 8 | 24 | 25 | 101 |
Z818-2C10 | 10 | 30 | 40 | 157 |
Z818-2C13 | 13 | 39 | 67 | 265 |
Z818-2C16 | 16 | 48 | 100 | 402 |
Z818-2C18 | 18 | 54 | 125 | 509 |
Z818-2C20 | 20 | 60 | 160 | 628 |
Z818-2C22 | 22 | 66 | 190 | 760 |
NACM96 Welded G100 Alloy Steel Lifting Chain
KHOOM CODE | NOMINAL SIZE Dn (hli) | PITCH (hli) | Ua haujlwm LOAD LIMIT LWV (lbs) | QHOV TSEEB FORCE (phaus) |
ZN96C7/32 | 5.5 | 17.6 | 2700 | 10800 |
ZN96C9/32 | 7 | 22.9 | 4300 | 17200 |
ZN96C5/16 | 8 | 26.4 | 5700 | 22800 |
ZN96C3/8 | 10 | 32 | 8800 | 35200 |
ZN96C1/2 | 13 | 41.6 | 15000 | 60000 |
ZN96C5/8 | 16 | 51.2 | 22600 | 90400 |
ZN96C3/4 | 20 | 64 | 35300 | 141200 |
ZN96C7/8 | 22 | 70.4 | 42700 | 170800 |
ZN96C1 | 26 | 83.2 | 59700 | 238800 |
ZN96C1-1/4 | 32 | 102.4 | 90400 | 361600 |
NTA:
● Forged thiab Quenched Super Alloy Steel
Least Tsawg kawg 25% muaj zog dua li qib ib txwm 80 nqa nqa
● Xiav pleev xim lossis pleev xim dub electrophoresis
● Kev nyab xeeb zoo 4: 1
Ntim:Feem ntau ntim hauv cov nruas hlau ntawm cov hlau pallets.
CEEB TOOM:
Qib 100 nqa cov saw no yuav tsum tau tshuaj xyuas los ntawm tus neeg tshwj xeeb tsawg kawg txhua lub hlis lossis ntau dua thaum nws siv nyob rau ib puag ncig kev ua haujlwm hnyav.
Cov lus qhia:
 | Smooth Weld Part& Zoo Link Zoo |
 |
Ntshiab Stamping& Xim Xiav Xim Xiav |
 | Dub Electrophoresis nto |
 | G80 thiab G100 Lifting Chain Show hauv Exhibition |
QHOV TEEB MEEM TEST
 |  |
| Ua txhaum ntawm qhov txuas yog tsis siv tau | Tsim nyog |
Z2 ZOO TSHAJ PLAWS
NTAWV QHIA:
FAQ:
1. Q: Koj puas yog tuam txhab lag luam lossis chaw tsim khoom?
A: Peb yog lub hoobkas. Peb muaj ntau dua 13 xyoos kev paub hauv kev nqa khoom. Feem ntau tsom mus rau ua thiab muab TOP cov khoom lag luam zoo hauv tus nqi nruab nrab rau peb cov neeg siv khoom. Thiab pab lawv tsim thiab nthuav kev lag luam mus sij hawm ntev hauv lawv cov lag luam.
2. Q: Koj puas muab cov qauv? puas yog dawb lossis ntxiv?
A: Yog, peb tuaj yeem muab cov qauv dawb xwb tab sis tsis them tus nqi thauj khoom. Thaum tus nqi thauj khoom tuaj yeem txo qis hauv peb cov xaj tom qab yog tias peb qhib peb txoj kev koom tes lag luam.
3. Q: Cov khoom dab tsi koj feem ntau muab?
A: Dhau li ntawm qhov ua tau zoo tshaj plaws lub zog muaj zog saw hlau thiab sib dhos ua ke, peb tseem muab cov khoom nqa nqa, nqa cov khoom thiab cov cuab yeej siv dej hiav txwv.
Cim npe nrov: g100 nqa saw, Suav teb, cov chaw muag khoom, chaw tsim khoom, lub Hoobkas, kev cai, lag luam wholesale, nqi
